With the Multi EV multi tester you are able to make important measurements in hybrid and electric vehicles.
After de-energizing the vehicle, a check is required by means of a measurement. This measurement ensures that you can work safely on the vehicle. It is therefore important that this is done with measuring equipment that is suitable for this. This meter complies with CAT III 1000V and therefore complies with the NEN9140.
It is possible to perform an insulation check or diagnosis on insulation faults measurement. You can compare these measurements with a resistance measurement, but now the meter offers a high voltage: 50V, 100V, 250V. 500V, or 1000V. The voltage you have to choose is equal to or slightly higher than the maximum voltage that prevails in the high voltage section. Due to the possibility to also select 50V and 100V, this EV multi tester is now also suitable for current and future 48V systems and piezo injectors can be checked for insulation errors under load.
You can also perform an earth continuity test (also known as potential equalization). During this measurement you perform a resistance measurement using a test current of 200 mA (prescribed by the vehicle manufacturer) and thus you can determine this resistance very accurately and under load. Resolution = 0.001ohm (accuracy of 1 milliohm)
